Single Cell Raw Data Processing

Kerry Cobb

Goals

  • Understand the steps for processing raw single cell RNA-seq data
  • See how to run software for each processing step
  • See scripts for running each piece of software on HPC

Dataset

  • Caron et al. 2020
  • Childhood acute lymphoblastic leukemia
  • Most common childood cancer
  • Precursor B-cell acute lymphoblastic leukemia (B-ALL)
    • ~85% of cases
    • Good prognosis
  • T-cell acute lymphoblastic leukemia (T-ALL)
    • ~15% of cases
  • Some patients are refractory or will relapse and succumb
  • Compare 4 B-ALL, 2 T-ALL, and 3 healthy controls
  • Cells are bone marrow mononuclear cells (BMMCs)
  • Each sample sequenced on a different lane of Illumina
    • Why is that not ideal?

Workflow

  1. Data download
  2. Quality control
  3. Mapping & alignment
  4. Feature counting

Logging in to the HPC

ssh genomeuser<#>@xanadu-submit-ext.cam.uchc.edu

Git Repository

  • All of the code and data for this workshop is available on GitHub.

  • You can clone the repository to your home directory on the HPC using the following command:

git clone https://github.com/CBC-UCONN/Single-Cell-Transcriptomics.git

Reference Genome

  • Required for mapping reads
  • NCBI & Ensemble are good source
  • For examples see:
    • resources/Homo_sapiens.GRCh38/download.sh
    • resources/GRCh38.p14/GRCh38_download.sh

FASTA Format

  • Common format for storing nucleotide sequences
  • Typically used for reference genomes
  • Each sequence is represented by two lines:
    1. Identifier line (starts with ‘>’)
    2. Sequence line (the actual nucleotide sequence)
  • Example:
>SEQ_ID
GATTTGGGGTTTAAAGGGTGACCTGGTAGG

Data Download

  • NCBI Sequence Read Archive (SRA)
  • https://www.ncbi.nlm.nih.gov/bioproject/PRJNA548203
  • Use SRA Toolkit to download
  • include-technical
    • Necessary to obtain Cell and UMI barcodes
  • See: leukemia/scripts/01_download.sh

FASTQ Format

  • Typical raw data format for sequencing reads
  • Typically separated into two or more files
    • One for each end of a read, if paired
    • Technical reads such as barcodes or UMIs
  • Each read is represented by four lines:
    1. Header (starts with ‘@’)
    2. Sequence (the actual nucleotide sequence)
    3. Separator (starts with ‘+’)
    4. Quality score (ASCII-encoded quality scores for each nucleotide)
  • Example:
@SEQ_ID
GATTTGGGGTTTAAAGGGTGACCTGGTAGG
+
!''*((((***+))%%%++)(****)())-+**--1

FASTQ Format - Quality Scores

  • Quality scores are encoded using ASCII characters
  • Each character represents a 2 digit quality score for the corresponding nucleotide
    • This permits more efficient storage
  • The quality score is a measure of the confidence in the accuracy of the base call
  • The higher the quality score, the more reliable the base call
  • Calculated as -10 * log10(P) where P is the probability of an incorrect base call
  • Examples:
    • Q = 10, P = 0.1 (10% chance of error)
    • Q = 30, P = 0.001 (0.1% chance of error)

FASTQ Format - Headers

  • The header line contains metadata about the read
  • Illumina headers typicallly look like this:
@HWUSI-EAS100R:6:73:941:1973#0/1

The components of the header are:

  • HWUSI-EAS100R: the unique instrument name
  • 6: flowcell lane
  • 73: tile number within the flowcell lane
  • 941: ‘x’-coordinate of the cluster within the tile
  • 1973: ‘y’-coordinate of the cluster within the tile
  • #0: index number for a multiplexed sample (0 for no indexing)
  • /1: the member of a pair, /1 or /2

Annotations

  • Annotations provide additional information about the sequences
  • They can include gene names, descriptions, and other metadata
  • Annotations are often stored in separate files, such as GTF or GFF files
  • GTF (Gene Transfer Format) and GFF (General Feature Format) are common formats
  • Annotation files contain information about gene structures, such as exons, introns, and transcripts
  • GTF & GFF files are similar but GFF can include more complex features and relationships
  • GFF is preferred

Annotations

  • Can be downloaded from Ensembl or NCBI
  • 10X Genomics provides a custom annotation file for human and mouse

Quality Control

  • Quality of reads
  • Quantify of reads
  • Adapters Contamination

Adapter Contamination

Can occur if insert size is too short

Illumina Inc.

ECSEQ

Fastqc

  • Evaluates several metrics for a FASTQ file
  • Provides a summary of the quality of the reads
  • Generates an HTML report with visualizations and statistics
  • Can be run with the command:

Multiqc

  • Consolidates multiple reports from FastQC and other tools
  • Generates a single HTML report with visualizations and statistics
  • Useful for comparing multiple samples or conditions

Mapping & Alignment

Mapping & Alignment

  • Methods can be broadly categorized into three types:
    1. Spliced alignment
    2. Contiguous alignment
    3. Lightweight mapping (pseudoalignment)
  • Alignment-based methods provide easily interpreted mapping scores
  • Lightweight methods are faster

Spliced Alignment

  • Reads can align across multiple distinct segments of a reference

Contiguous Alignment

  • Reads require a continuous segment of the reference
  • Large gaps such as introns are not allowed
  • Faster
  • Requires annotated transcript sequences as reference
    • Not suitable for single nucleus RNA-seq data
  • Can be used with augmented transcriptome
    • Full length unspliced transcripts or excised intronic sequences

STARsolo

  • Much faster alternative to Cell Ranger
  • Produces near identical output to Cell Ranger
  • Cell Ranger uses STAR for alignment
  • STAR can be used for other types of single cell RNA-seq data
    • No need to learn a new tool or make large modifications to the workflow
  • Requires an index for the reference genome}

STARsolo Indexing

  • -sjdbOverhang
    • Length of the longest read minus 1
    • For example, if the longest read is 150 bp, then -sjdbOverhang should be set to 149

STARsolo Args

  • soloCBwhitelist
    • The allowed cell barcodes
    • These are packged with cell ranger
  • soloUMIlen
  • soloType
    • Type of single-cell RNA-seq
    • Probaly will want to use CB_UMI_Simple
      • One UMI and one cell barcode of fixed length
  • soloUMIlen
    • 10 for v2
    • 12 for >v3
  • readFilesIn
    • 1st file is cDNA read
    • 2nd file barcode (cell+UMI)
  • readFilesCommand
    • zcat if gzipped
  • soloOutFormatFeaturesGzipped
    • compress output mtx files, scanpy expects these to be .gz

SAM & Bam file formats

  • Output is a SAM file
  • SAM (Sequence Alignment/Map) is a text format for storing aligned reads
  • It contains information about the alignment of each read to the reference genome
  • SAM files are human-readable, but can be large
  • They can be compressed to BAM format for storage and efficiency
    • They are compressed and indexed for efficient access
    • Not human-readable
  • SAM/BAM files can be viewed with tools like IGV or samtools
  • They are used for downstream analyses like feature counting and variant calling
  • Example SAM file: @HD VN:1.0 SO:unsorted @SQ SN:chr1 LN:248956422 @RG ID:group1 SM:sample1 @PG ID:program1 PN:STAR VN:2.7.9a read1 0 chr1 100 60 10M1I5M2D3M * 0 0 ACGTACGTAC IIIIIIIIIIIIIIIIIIII AS:i:10 NM:i:1

CIGAR String

  • CIGAR (Compact Idiosyncratic Gapped Alignment Report) string is a part of the SAM/BAM format
  • It describes how the read aligns to the reference genome
  • It consists of a series of operations, each represented by a character and a number
  • Common operations include:
    • M: match or mismatch
    • I: insertion
    • D: deletion
    • N: skipped region (intron)
    • S: soft clipping (part of the read is not aligned)
  • Example CIGAR string: 10M1I5M2D3M
    • This means 10 matches, 1 insertion, 5 matches, 2 deletions, and 3 matches

Feature Counting

  • Quantify abundance of each gene using UMIs
  • STAR-solo also does feature counting for us

Feature Counts

Single Cell Analysis

Up next!
